MIL-DTL-18295F
Tolerances
Dimension
Plus
Minus
Dimension
Plus
Minus
Dimension
Plus
Minus
A
0.065d
None
G
0.090d
None
M
0.07d
None
(1.651)
(2.286)
(1.78)
C
0.285d
None
H
As
As
N
0.07d
None
(7.239)
required
required
(1.78)
D
0.30d
None
J
0.065d
None
P
0.20d
None
(7.620)
(1.651)
(5.08)
E
0.065d
None
K
As
As
X
0.065d
None
(1.651)
required
required
(1.651)
F
0.083d
None
L
0.065d
None
0.065d
None
Y
(2.108)
(1.651)
(1.651)
FIGURE 5a. Swivel shackle details - Continued.
Taper pin and dovetail dimensions are for all components requiring same (dimensions are minimum).
C
1° MIN
(CONE DEGREE)
TAPER PINS
D
A
B
DOVETAIL CHAMBER
Dimensions:
A. Equals large end diameter of pin at C.
B. 2 times dimension A.
C. Taper pin large end diameter = 0.30 in. (7.62 mm) of chain size the component is designed as. Pin
to fit in intended hole with interference fit as specified in ASME B4.1.
D. 1.12 times dimension A.
FIGURE 5b. Riser swivel shackle taper pin and dovetails.
34
