MIL-DTL-18295F
All dimensions in inches (mm).
Nominal
A
A
B
B
C
C
D
D
chain size
(min)
(max)
(min)
(max)
(min)
(max)
(min)
(max)
(d)(in.) (mm)
1.75
2.25
2.38
11.50
11.67
4.19
4.32
1.38
1.44
(44.45)
(57.15)
(60.45)
(292.10)
(296.42)
(106.43)
(109.73)
(35.05)
(36.58)
2.00
2.50
2.63
13.73
14.03
4.91
5.21
1.64
1.74
(50.80)
(63.50)
(66.80)
(348.74)
(356.36)
(124.71)
(132.33)
(41.66)
(44.20)
2.25
2.75
2.87
14.50
14.69
5.37
5.50
1.73
1.83
(57.15)
(69.85)
(72.90)
(368.30)
(373.13)
(136.40)
(139.70)
(43.94)
(46.48)
2.50
3.00
3.13
16.16
16.34
5.92
6.05
1.92
2.02
(63.50)
(76.20)
(79.50)
(410.46)
(415.04)
(150.37)
(153.67)
(48.77)
(51.31)
2.75
3.50
3.63
17.70
17.88
6.47
6.60
2.11
2.21
(69.85)
(88.90)
(92.20)
(449.58)
(454.15)
(164.34)
(167.64)
(53.60)
(56.13)
3.00
3.75
3.83
19.21
19.33
6.82
7.28
2.28
2.40
(76.20)
(95.25)
(97.28)
(487.93)
(490.98)
(173.23)
(184.91)
(57.91)
(60.96)
3.50
4.25
4.33
23.90
24.08
8.77
8.90
2.85
2.97
(88.90)
(107.95)
(109.98)
(607.06)
(611.63)
(222.75)
(226.06)
(72.39)
(75.44)
4.00
4.75
4.87
26.22
26.40
9.61
9.74
3.13
3.25
(101.60)
(120.65)
(123.70)
(665.99)
(670.56)
(244.09)
(247.40)
(79.50)
(82.55)
C
MFG, FM3,
CHAIN SIZE
RANGE
(SEE FIGURE 20)
IF WELDED
B
A
D
FIGURE 8. Pear link.
