MIL-DTL-18295F
All dimensions in inches (mm).
Nominal
chain size (d)
A
A
B
B
(in.) (mm)
(min)
(max)
(min)
(min)
1.75 (44.45)
3.41 (86.6)
3.59 (91.19)
8.78 (223.01)
9.23 (234.44)
2.00 (50.80)
3.66 (96.9)
3.84 (97.54)
10.24 (260.01)
10.76 (273.31)
2.25 (57.15)
5.25 (133.35)
5.50 (139.70)
11.70 (297.18)
12.30 (312.42)
2.50 (63.50)
5.25 (133.35)
5.50 (139.70)
11.70 (297.18)
12.30 (312.42)
2.75 (69.85)
5.25 (133.35)
5.50 (139.70)
11.70 (297.18)
12.30 (312.42)
3.00 (76.20)
5.50 (139.70)
5.75 (146.05)
13.84 (351.54)
13.16 (334.26)
3.50 (88.90)
5.75 (146.05)
6.00 (152.40)
13.16 (334.26)
13.84 (351.54)
4.00 (101.60)
7.31 (185.67)
7.69 (195.38)
19.00 (482.60)
19.95 (506.73)
A
B
MARKING
SEE FIGURE 20
FIGURE 4. Ground ring.
31
