MIL-DTL-18295F
All dimensions in inches (mm).
Nominal
1.75
2.00
2.25
2.50
2.75
3.00
3.50
4.00
chain size
(44.45)
(50.80)
(57.15)
(63.50)
(69.85)
(76.20)
(88.90)
(101.60)
(d)(in.)(mm)
A
11.97
13.47
14.97
16.47
18.34
19.72
23.22
25.40
(min)
(304.04)
(342.14)
(380.24)
(418.34)
(465.84)
(500.89)
(589.78)
(645.16)
A
12.03
13.53
15.03
15.63
18.41
19.78
23.28
25.60
(max)
(305.56)
(343.66)
(381.76)
(397.00)
(469.61)
(502.41)
(591.31)
(650.24)
B
7.72
8.69
9.65
10.78
11.98
12.84
14.97
17.34
(min)
(196.09)
(220.73)
(245.11)
(273.81)
(304.29)
(326.14)
(380.24)
(440.44)
B
7.78
8.75
9.72
10.84
12.03
12.91
15.03
17.40
(max)
(197.61)
(222.25)
(246.88)
(275.34)
(305.56)
(327.91)
(381.76)
(441.96)
C
2.33
2.61
2.90
3.59
3.97
4.38
4.67
6.33
(min)
(59.18)
(66.29)
(73.66)
(91.19)
(100.84)
(111.25)
(118.62)
(160.78)
C
2.61
2.95
3.28
4.03
4.47
4.62
5.26
6.67
(max)
(66.29)
(74.93)
(83.31)
(102.36)
(113.54)
(117.35)
(133.60)
(169.42)
D
1.97
2.22
2.47
2.84
3.16
3.34
3.84
4.34
(min)
(50.03)
(56.38)
(62.74)
(72.14)
(80.26)
(84.84)
(97.54)
(110.24)
D
2.03
2.28
2.53
2.90
3.22
3.40
3.90
4.40
(max)
(51.56)
(57.91)
(64.26)
(73.66)
(81.79)
(86.36)
(99.06)
(111.76)
E
2.34
2.65
2.91
3.25
3.34
3.47
4.59
5.22
(min)
(59.44)
(67.31)
(73.91)
(82.55)
(84.84)
(88.14)
(116.58)
(132.58)
E
2.47
2.78
3.06
3.30
3.40
3.63
4.72
5.38
(max)
(62.74)
(70.61)
(77.72)
(83.82)
(86.36)
(92.20)
(119.89)
(136.65)
F
2.47
2.78
3.06
3.44
3.81
4.06
4.72
5.38
(min)
(62.74)
(70.61)
(77.72)
(87.38)
(96.77)
(103.12)
(119.89)
(136.65)
F
2.53
2.84
3.12
3.50
3.87
4.17
4.78
5.91
(max)
(64.26)
(72.14)
(79.25)
(88.90)
(98.30)
(105.92)
(121.41)
(150.11)
G
1.30
1.45
1.64
1.80
1.89
2.11
2.61
2.87
(min)
(33.02)
(36.83)
(41.66)
(45.72)
(48.00)
(53.59)
(66.29)
(72.90)
G
1.33
1.51
1.67
1.83
1.92
2.18
2.64
2.91
(max)
(33.78)
(38.35)
(42.42)
(46.48)
(48.77)
(55.37)
(67.06)
(73.91)
DOVETAIL
D
SEE NOTE 3
E
C
F
E
B
PIN
G RAD
A
Notes:
1. For dovetail and pin dimension see Figure 5b.
2. All chain joining links must be compatible with the common stud link of the same nominal size.
3. Draft angle between 3 degrees and 10 degrees.
FIGURE 2. Chain joining link.
28
