MIL-DTL-18295F
All dimensions in inches (mm).
Nominal
G
G
H
H
I
I
K
chain size
(min)
(max)
(min)
(max)
(min)
(max)
(d) (in.) (mm)
1.75
2.22
2.33
5.80
6.10
6.83
7.18
4.90
(44.45)
(56.39)
(59.18)
(147.32)
(154.94)
(173.48)
(182.37)
(124.46)
2.00
2.54
2.67
6.63
6.97
7.80
8.20
5.60
(50.80)
(64.52)
(67.82)
(168.40)
(177.04)
(198.12)
(208.28)
(142.24)
2.25
2.85
3.00
7.46
7.84
8.78
9.23
6.30
(57.15)
(72.39)
(76.20)
(189.45)
(199.14)
(223.01)
(234.44)
(160.02)
2.50
3.17
3.33
8.29
8.71
9.75
10.25
7.00
(63.50)
(80.52)
(84.58)
(210.56)
(221.23)
(247.65)
(260.35)
(177.80)
2.75
3.49
3.66
9.12
9.58
10.73
11.28
7.70
(69.85)
(88.65)
(92.96)
(231.65)
(243.33)
(272.54)
(286.51)
(195.58)
3.00
3.80
4.00
9.95
10.46
11.70
12.30
8.40
(76.20)
(96.52)
(101.60)
(252.73)
(265.68)
(297.18)
(312.42)
(213.36)
3.50
4.44
4.66
11.60
12.20
13.65
14.35
9.80
(88.90)
(112.78)
(118.36)
(294.64)
(309.88)
(346.71)
(364.49)
(248.92)
4.00
5.07
5.33
13.26
13.94
15.60
16.40
11.20
(101.60)
(128.78)
(135.38)
(336.80)
(354.08)
(396.49)
(416.56)
(284.48)
Notes:
1. Eye for pin J = (1.048) (26.62 mm)J, + (0.03) (0.76 mm)J, - 0.00.
Eye for pin L = (1.048) (26.62 mm)J, + (0.03) (0.76 mm)J, - 0.00.
Dimension L = (1.2) (30.5 mm)d, + (0.03) (0.76 mm)d, - 0.00.
Dimension N = (1.4) (35.6 mm)d, + (0.05) (1.3 mm)d, - 0.00.
Dimension J = (1.56) (39.60 mm)d, + (0.03) (0.76 mm)d, - 0.00.
2. For pin dimension and dovetail dimension see figure 5b.
I
G
MFG, FM3, CHAIN
SIZE RANGE (SEE
H
FIGURE 20)
PIN
DOVETAIL
J
G
L
N
K
FIGURE 10. Joining shackle.
39
