MIL-DTL-2710C
d.
Hairpin:
(1) Chemical composition.
4.2.1.3 Finished detachable link for breaking load test. One finished detachable link for
a breaking load test. The detachable link used for the proof test from 4.2.1.1(g) above with the
hairpin and plug installed, may be used for the breaking test.
4.2.1.4 Finished detachable link, without hairpin or plug, for finish inspection. One
finished detachable link, without the hairpin or plug installed, for a finish (paint) inspection.
4.3 Conformance inspection. Detachable link samples shall be selected in accordance
with 4.3.1 and shall be inspected in accordance with table VI. The samples shall be clean,
bright, and free of paint or other coating which would tend to conceal defects during the testing
and inspection (see 6.3).
TABLE VI. Conformance examinations and tests.
Requirement
Examination or
Inspection
paragraph
test paragraph
Detachable Link
Proof load test
3.13
4.5.3
Breaking load test
3.14
4.5.2
Finish
3.17
4.4.7, 4.4.9
C-Link component
Tensile test
3.4
4.5.4
Dimension conformance
3.7
4.4.1
Draft angles
3.7.1
4.4.1.1
Brinell hardness 1
3.5
4.5.6
Surface
3.8
4.4.2
Markings
3.15, 3.15.1
4.4.4
Identification numbers
3.16
4.4.5
Right and left hand coupling plates
Tensile test
3.4
4.5.4
Dimension conformance
3.7
4.4.1
Draft angles
3.7.1
4.4.1.1
Brinell hardness 1
3.5
4.5.6
Surface
3.8
4.4.2
Markings (right hand coupling plate only)
3.15
4.4.4
Identification numbers
3.16
4.4.5
Fit
3.10
4.4.6
Taper pin
Dimension conformance
3.7
4.4.1
Surface
3.9
4.4.3
Engagement
3.11
4.4.7
Brinell hardness 1
3.6
4.5.5
12
