MIL-DTL-83140B
1.3 Part or identifying number (PIN). The PIN to be used for preformed stainless steel
wire rope acquired to this specification is created as follows:
M 83140 - XX - XX
Diameter (in 1/32s): 5 = 5/32
6 = 3/16
7 = 7/32
8 = 1/4
10 = 5/16
12 = 3/8
16 = 1/2
20 = 5/8
Type:
1 - I - Rotation-resistant for hoisting (vertical)
operations
2 - II - Rotation-resistant for winching
(vertical, horizontal, or at-angle) operations
Specification number
Denotes military specification
Example:
M83140-1-12 is 3/8 diameter, type I wire rope
See table I for applicable type/diameter combinations.
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this
specification. This section does not include documents cited in other sections of this specification or
recommended for additional information or as examples. While every effort has been made to ensure
the completeness of this list, document users are cautioned that they must meet all specified
requirements of the documents cited in sections 3 and 4 of this specification, whether or not they are
listed.
2.2 Government document.
2.2.1 Specification. The following specification forms a part of this document to the
extent specified herein. Unless otherwise specified, the issue of this document is that cited in the
solicitation or contract.
DEPARTMENT OF DEFENSE SPECIFICATION
MIL-DTL-781
- Terminal, Wire Rope Swaging, General
Specification for
2
