RR-W-410G

FIGURE 36. Type III, marine (cables), class 6, 6 by 42 tiller

or hand control ropes.

FIGURE 37. Type IV, miscellaneous, class 1, 5 by 19 (marline- clad), construction 1,

(2 operations).

FIGURE 38. Type IV, miscellaneous, class 1, 5 by 19 (marline- clad), construction 2, (Warrington).

FIGURE 39. Type IV, miscellaneous, class 1, 5 by 19 (marline- clad), construction 3, (Filler wire).
